WindBine TM Beacon Light Shroud - Part #BEACLS

This WindBine TM Part includes the drawing and electronic file for the Beacon Light Shroud that the Inventor used this part to mount and shield the two LED Beacon Lights for his WindBine TM machine!  This part mounts on top of the Beacon Light Mast and has automatic settings for turning on at night through the WindBine TM Graphical User Interface (GUI), available on the Slingshot WEST Store, that the Inventor used to control, monitor and diagnose all aspects of his WindBine TM machine!

Purchase full drawing that includes the electronic file!

WindBine TM
Beacon Light Shroud
Part # BEACLS
Material: 11 gauge 5052 Aluminum
Finish: None
Thickness: 0.091" wall
Weight:  0.37 lbs
Pieces required: 2
Scale: 1/4
Dim's in inches
May 20/19
'Easy-View' Drawing

Slingshot WEST Inc.
Angus Tocher
