WindBine TM Bottom Roll Plate Aft - Part #FP4

This WindBine TM Part includes the drawing and electronic file for the Bottom Roll Plate Aft for laser or water jet cut that the Inventor used to build his WindBine TM! Two of the plates are bolted together to get a final thickness of 1/2" so that they are easily punched or water or laser jet cut and sandwiched together to cancel any warpage that may be incurred in the cutting process!

Purchase full drawing that includes the electronic file for making the part!

WindBine TM
Bottom Roll Plate Aft
Part # FP4
Material: 5052 aluminum
Finish: Powder Coat Half SAND
                    (down side as punched, convex side)
                    Half NONE
Thickness: 1/4"
Weight: 14.3 lbs
Pieces required: 2
Scale: 1/12
Dim's in inches
April 8 2013
'Easy-View' Drawing

Slingshot WEST Inc.
Angus Tocher
