WindBine TM Fuselage Skin 1 and 14 LW - Part #FS1N14LW

This WindBine TM Part includes the drawing and electronic file for the Fuselage Skin 1 and 14 LW (leeward) that the Inventor used to form the very strong semi-monocoque fuselage of his WindBine TM!

Purchase full drawing that includes the electronic file for making the part!

WindBine TM
Fuselage Skin 1 and 14 LW
Part # FS1N14LW
Material: 5052 sheet aluminum
          20 gauge
Finish: Symmetric
        Powder Coat 1 side only.
        Sand
Thickness: 0.032"
Weight:  approx 3.42 lbs
Pieces required: 2
Scale: 1/8
Dim's in inches
March 27/24
'Easy-View' Drawing

Slingshot WEST Inc.
Angus Tocher
