WindBine TM Fuselage Skin 3 and 12 Side - Part #FS3N12Side

This WindBine TM Part includes the drawing and electronic file for the Fuselage Skin 3 and 12 Side that the Inventor used to form the very strong semi-monocoque fuselage of his WindBine TM! Note: (WW) Fuselage Skins incorporate vortex generator tabs to bend out 90 degrees that the Inventor used to reduce fuselage aerodynamic drag!

Purchase full drawing that includes the electronic file for making the part!

WindBine TM
Fuselage Skin 3 and 12 Side
Part # FS3N12Side
Material: 5052 sheet aluminum
          14 gauge
Finish: Not Symmetric
        Powder Coat BOTH SIDES
        Sand
Thickness: 0.0641"
Weight:  approx 6.28 lbs
Pieces required: 4
Scale: 1/8
Dim's in inches
March 28/24
'Easy-View' Drawing

Slingshot WEST Inc.
Angus Tocher
