WindBine TM Roller Mount Punched - Part #RLLMNT

This WindBine TM Part includes the drawing and electronic file for the Roller Mount Punched that the Inventor used to mount the Rollers that track the pole and all his WindBine TM to easily turn accurately into the wind for efficient operation! This part is best water or laserjet cut as punching 1/4" steel is hard on the punch tools!

Purchase full drawing that includes the electronic file!

WindBine TM
Roller Mount Punched
Part # RLLMNT
Material: 1/4" Mild Steel Plate
Finish: Powder Coat Sage
Thickness: 0.25"
Weight:  2.9 lbs
Pieces required: 20
Scale: 1/3
Dim's in inches
Feb 5/14
'Easy-View' Drawing

Slingshot WEST Inc.
Angus Tocher
