WindBine TM Short Brace - Part #SBRC

This WindBine TM Part drawing is for the Short Brace! These Brace parts are 3" X 3"  aluminum square tubing of 3/16" wall that the Inventor used to brace the Fins and Wings to the Fuselage of his WindBine TM!

Purchase full drawing!

WindBine TM
Short Brace for WB IV
Part # SBRC
Material: 3" X 3" Alum Square Tube
Finish: Powder Coat Sand
Thickness: 3/16" wall
Weight:  9.9 lbs
Pieces required: 8
Scale: 1/8
Dim's in inches
March 23/17
'Easy-View' Drawing

Slingshot WEST Inc.
Angus Tocher
